AVXB Specification

The AVXB is a universal bus connection, often connecting to a DSP or FPGA by the means of a high density Samtec connector. This connector accepts a range of modular products, which are mounted above the base board. Utilising the standard AVXB base module, a flexible system can be tailor made by attaching a wide variety of daughter modules.


One control channel port including IC2 and Global clock connections.
Two data buses
A set of power supplies: +3.3, +5 and +12Volts
Two-extra mounting holes to hold base and modules together.
Module Description
AV909 Dual Multi-channel Video Decoder Interface Module
AV939 Single DVI Transceiver Module
AV949 Dual CameraLink Receiver Module
AV959 Dual 40Msps ADC & Dual 125Msps DAC Module
AV969 Multiformat SDTV/HDTV Video Decoder Module
AV979 Multiformat SDTV/HDTV Video Encoder Module
